Ortofon Hi-Fi 2M Blue Moving Magnet Cartridge

5705796080025

Call or Email Us now for a better deal!

$332 Save 10%
$369
*Seen it cheaper elsewhere? We do price match.
Options
Quantity

The 2M Blue Series features:

  • an improved engine, which provides an increased output of 5.5mV
  • Nude Elliptical diamond and split pole pins with a copper wire



Technical data 2M Blue / 2M Blue Verso


Output voltage at 1000 Hz, 5cm/sec. 5,5 mV
Channel balance at 1 kHz  1,5 dB
Channel separation at 1 kHz 25 dB
Channel separation at 15 kHz 15 dB
Frequency range at - 3dB 20-25.000 Hz
Frequency response 20-20.000 Hz + 2 / - 1 dB
Tracking ability at 315Hz at recommended tracking force 80 µm
Compliance, dynamic, lateral 20 µm/mN
Stylus type Nude Elliptical
Stylus tip radius r/R 8/18 µm
Tracking force range 1,6-2,0g (16-20 mN)
Tracking force, recommended 1,8 g (18 mN)
Tracking angle 20°
Internal impedance, DC resistance 1,3 kOhm
Internal inductance 700 mH
Recommended load resistance 47 kOhm
Recommended load capacitance 150-300 pF
Cartridge colour, body/stylus Black/Blue
Cartridge weight 7,2 g
